Feasycom Bluetooth AoA Kit K3 is a high accuracy RTLS Evaluation kit Based on Bluetooth AoA technology.
It contains 1 AoA gateway and 6 tags. The gateway supports POE/DC power supply and is easy to deploy and test.
The purpose of K3 is to help customers quickly complete prototype verification and accelerate project implementation progress.
High Accuracy: All BLE devices offer precision ranging from 0.1 to 0.5 meters
High Capacity: Supports high tag density, ideal for large-scale projects
Long Battery Life: BLE tag battery life of up to 10 years
Real-Time Transmission: Ultra-low latency ensures minimal data transmission delay
Cost-Effective: Benefits from the cost efficiency of the Bluetooth ecosystem
Compact Size: Smallest tags are as compact as a coin
| Item | Description |
| Bluetooth Version | BLE 5.4 |
| Installation Method | Ceiling-mounted or wall-mounted |
| Power Supply | PoE or DC power |
| Maximum Installation Height | 10 meters |
| Coverage Range | Coverage radius is twice the installation height |
| Accuracy | 0.1–1 meter |
| Dimensions (cm) | 18 × 18 × 3.5 |
| Bluetooth AoA Tag | FSC-BP10x Series |
| Bluetooth Version | BLE 5.1 / 5.4 |
| Button | Optional SOS function |
| Gravity Sensor | Included |
| LED Indicator | Included |
| Customizable | Yes |
| Configurable | Yes |
