Feasycom FSC-BP101Y is a Bluetooth BLE USB Dongle Transmitter that can connect to laptops to provide people with convenient internet service.
|
Model
|
FSC-BP101Y
|
|
Bluetooth Version
|
Bluetooth v5.0 Dual mode
|
|
频率
|
2.400 - 2.480 GHz
|
|
传输功率
|
+5 DBM (Maximum)
|
|
Receive Sensitivity
|
-95 DBM (Typical)
|
|
Raw Data Rates(Air)
|
3 Mbps
|
|
Modulation
|
GFSK
|
|
Type
|
PCB Coil antenna
|
|
Gain
|
2dBi(Max)
|
|
Radiation diagram
|
Omnidirectional
|
|
Power supply
|
USB
|
|
Voltage
|
5V (TYP.)
|
|
Material
|
ABS plastic
|
|
Color
|
Black
|
|
Size
|
32.8 * 16.2 *8 (mm)
|
|
Protection
|
IP40
|
|
工作温度
|
-40°C to +70°C
|
|
Storage temperature
|
-40°C to +70°C
|
