FeasyBeacon FSC-BP106 is an innovative waterproof IP67 Bluetooth 5.1 Low Energy smart beacon, it simultaneously supports iBeacon, Eddystone (e.g. URL, UID), AltBeacon for broadcasting and provides the ability to advertise up to 10 slots of advertising frames.
FSC-BP106 has the design patent of sun-flower-shape Bluetooth beacon, it’s a work of art decorating your life with the vitality and optimism.
With the iOS & Android FeasyBeacon SDK, the developers can take advantage of the flexibility of the SDK and focus on their own application, such as Broadcast, Proximity Marketing, Digital Signage, Indoor and Outdoor Location, Asset Tracking, Vehicle Tracking, 等. Meanwhile, FeasyBeacon SDK compiled app is available to download from both the iOS and Android platform (search ‘FeasyBeacon’ to download).
| Item | Description |
| Advertising Format | Eddystone (URL/ UID), iBeacon, AltBeacon |
| Configuring Method | FeasyBeacon SDK compiled app (e.g. FeasyBeacon app) |
| Advertising Interval | Default 1300 ms, range from 100 ms to 2000 ms |
| Security | Access password required, Default Pin Code 000000 |
| Max Number of Broadcast | 10 Slots configurable advertising frames |
| Default Broadcast Interval | 1300 ms for iBeacon & Eddystone |
| System Compatibility | iOS 7.0+, Android 4.3+ |
| Advertising Distance | Up to 500m (open area) |
| Firmware Upgrading | OTA (upgrade firmware over the air) |
| Item | Description |
| 芯片组 | TI CC2640R2F |
| Bluetooth Version | 蓝牙 5.1 |
| TX power | -23 dBm 到 +5 DBM |
| Antenna | Ceramic antenna |
| Power Supply | CR3032 |
| Battery Life | 2 Years (ADV Interval = 1300 ms; TX Power = 0 DBM) |
| Material | ABS plastic |
| Color | White, Green, Blue, Yellow, or customized |
| Size | Diameter 47.5 mm, height 9.6 mm |
| Net weight | 19 g |
| Protection | IP67 |
| 工作温度 | -20°C to +60°C |
