The FSC-BP2381 Serial Bluetooth Adapter is an RS232 to Bluetooth protocol converter based on the DB9 interface. Utilizing Bluetooth 5.2 dual-mode technology, it enables wireless data transmission between serial devices and computers or mobile terminals. This product serves as a complete replacement for traditional wired serial connections, offering a stable and reliable wireless communication link.
|
Specification
|
Description
|
|
MODEL No.
|
(1) BP2381-F (DSUB FEMALE) (2) BP2381-M(DSUB MALE)
|
|
Bluetooth Version
|
蓝牙 4.2
|
|
Band Frequency
|
2.4 GHz
|
|
Coverage
|
Up to 200 meters (Open space)
|
|
Antenna
|
PCB on Board
|
|
Power Supply
|
USB, D-Sub 9pin
|
|
Supply Voltage
|
DC 5V, 100mA >USB BUS pwer
>RS-232C:DSUB Pin9
|
|
Interface
|
RS232C
|
|
Color
|
Black
|
|
Protocol
|
SPP [Serial Port Profile]
|
|
Baud rate
|
9600/19200/38400/57600/115200 bps
|
|
Temperature
|
Indoor working
|
|
LED States
|
Red,Blue
|
