FSC-BP309F is a USB interface Wlfl adapter.The adapter can only serve as a device that needs to be connected to the UsB host. The device power supply mode is UsB power supply, which is
provided by the host.FSc-BP309F has abundant AT command, complete function, efficient and safe communication and strong anti-interference ability.The main function is to provide cloud services for host devices with UsB interfaces.
| Model | FSC-BP309 |
| 芯片组 | CSR8510A10 |
| 蓝牙版本 | V4.0 dual mode |
| Transmission frequency | 2.402 - 2.480 GHz |
| Transmission Rate | Up to 3.0 Mbps |
| Transmission range | Up to 100 m (328 ft) In open air |
| External antenna gain | 2 dBi |
| Antenna interface | SMA |
| Transmit power | 18.5 DBM (Class 1) |
| 概况 | HFP 1.5, HSP 1.2, AVRCP 1.4, A2DP 1.2 |
| Driver software | CSR Harmony Wireless Software Stack |
| OS | Windows 10/8/7, Vista, XP |
| Product size | 60.9 * 16 mm |
