FeasyBeacon FSC-BP104E is a super long battery life Bluetooth 5.1 Low Energy smart beacon, it simultaneously supports iBeacon, Eddystone (e.g. URL, UID, TLM), AltBeacon for broadcasting and provides the ability to advertise up to 10 slots of advertising frames.
With the iOS & Android FeasyBeacon SDK, the developers can take advantage of the flexibility of the SDK and focus on their own application, such as Broadcast, Proximity Marketing, Digital Signage, Indoor Location, Asset Tracking, Vehicle Tracking, 等. Meanwhile, FeasyBeacon SDK compiled app is available to download from both the iOS and Android platform (search ‘FeasyBeacon’ to download).
| Item | Description |
| Advertising Format | Eddystone (URL/ UID/ TLM), iBeacon, AltBeacon |
| Configuring Method | FeasyBeacon SDK compiled app (e.g. FeasyBeacon app) |
| Advertising Interval | Default 1300 ms, range from 100 ms to 10000 ms |
| Security | Access password required, Default Pin Code 000000 |
| Max Number of Broadcast | 10 Slots configurable advertising frames |
| Default Broadcast Interval | 1300 ms for iBeacon & Eddystone |
| System Compatibility | iOS 7.0+, Android 4.3+ |
| Advertising Distance | Up to 400m (Tx Power = 2.5 DBM, in open area) |
| Firmware Upgrading | OTA (upgrade firmware over the air) |
| Button | Power ON/OFF |
| LED | Status |
| Item | Description |
| 芯片组 | DA14531 |
| Bluetooth Version | 蓝牙 5.1 |
| TX power | -19.5 dBm 到 +2.5 DBM |
| Antenna | F-shape PCB antenna |
| Power Supply | 2 * AAA (LR03), battery is included in the package |
| Power On | Long press central area for power on / off |
| Battery Life | Up to 10 Years (ADV Interval = 1300 ms; TX Power = 0 DBM， Battery Capacity=1000mAh) |
| Material | ABS plastic |
| Color | White or customized |
| Size | 55.7mm(L)*55.7mm(W)*16mm(H) |
| Net weight | 28g ( Without battery) |
| 工作温度 | -20°C to +60°C |
| * All battery information depends on the usage environment and many other factors, actual results may vary. The battery validity period is usually 10 years. | |
